Horing Lih Electronic Sounder and Beacon (EN) AH-03127-BS
Model: AH-03127-BS
Quick Overview
· 32 signal tones selectable by Dip switch.
· High sound output with low current consumption.
· High efficiency lense for maximum light output.
· Volume Control as standard.
· Two sets of IN and OUT terminals, easy for installation.
Description
Description
This electronic sounder is designed for use with fire alarm systems, security systems and industrial signaling systems. Combined sounder and beacon provides an audio-visual warning which is suitable for places where high sound output and visual indication is required.
Specification
- Voltage: 24V DC
- Current Consumption 24V DC (MAX): 40mA
- Sound Output 24V DC dB (A) at 1 meter: Max. 114
- Volume Control: 0 to -20dB adjustment
- Ingress Protection: IP44
- Ambient Temperature: -25°C ~ +80°C
- Material: Fire-proof plastic
- Dimensions: 92.5mm(Dia.) x 110mm(H)
- Weight: 278g
